ELiTE RXV Fleet
The RXV is known on golf courses everywhere for its superiority under the seat. Whether it's the industry-leading ELiTE™ Lithium powered by Samsung SDI or first-of-its-kind EX1 gas engine with closed-loop EFI, the RXV is a low-maintenance, high-performance golf cart you can always rely on. And now, the RXV creates a noticeable difference for golfers too, with a purpose-built dash and automotive pedals that completely streamline the way they play. Turn your course into a player's paradise with a custom fleet of RXVs.
Standard Features
- 1 x Samsung Lithium Ion 2.2 Maintenance Free Battery Pack with Battery Management System
- 56v Delta Q DC Lightweight Portable Charger,
- Top Assembly & Seating ( Choice of Stone Beige, Oyster or Black)
- 1 x Sand Bottle
- Split Windshield
- State of Charge Meter
- Scuff Guards
- Injection Moulded TPO Body finish
- Metallic Hubcaps ( Gold or Silver)
- Automatic E Park Brake
- AC Motor
- Induction Service Motor Brake
- Reverse Beeper
- Choice of Colour
Options/Accessories
- Sand bucket
- Club & ball washer
- Drinks Cooler Esky
- Message holder
- Lockable Glovebox doors
- Rainbag Cover ( Stone Beige, Oyster or Black)
- Premium Mushroom Seats
- USB Port
- 12 V Outlet
Specifications
Dimensions
Overall Length: 240 cm
Overall Width: 119 cm
Overall Height (no canopy): 121 cm
Overall Height (with canopy): 178 cm
Wheel Base: 167 cm
Front Wheel Track: 90 cm
Rear Wheel Track: 97 cm
Ground Clearance (at differential): 11 cm
Power
Power Source: 56 Volts DC
Motor Type: 48 Volt AC
Electric System: 56 Volt
Battery (qty/type): ELiTE 2.0, 56V Lithium ( Including Battery Management System)
Key or Pedal Start: Pedal Start
Battery Charger: Lithium World Charger 56VDC
Speed Controller: 235 Amp AC Controller
Drive Train: Motor Shaft Direct Drive
Transaxle: Limited Slip Differential
Gear Selection: Forward-Neutral-Reverse Integrated into Key Switch
Rear Axle Ratio: 16.99:1
Performance
Seating Capacity: 2 Person
Dry Weight (without battery): 275 Kg
Curb Weight: 298 Kg
Vehicle Load Capacity: 360 Kg
Outside Clearance Circle: 5.8 m
Intersecting Aisle Clearance: N/A
Speed (level ground): 13 - 24 kph ± 0.8 kph ( Programmable)
Towing Capacity: 3 E-Z-GO Golf Cars with Approved permanent tow bar
Steering & Suspension
Steering: Double-ended Rack and Pinion
Front Suspension: Independent A-arm Coil over Shock
Rear Suspension: Mono Leaf Springs with hydraulic Shocks
Service Brake: Induction Motor
Parking Brake: Automatic Electro Magnetic
Tyres: Turf Tyres 18 x 8.5 - 8 (4 Ply Rated)
Body & Chassis
Frame: Welded steel with powder coat protection
Front Body & Finish: Injection Moulded, TPO
Rear Body & Finish: Injection Moulded, TPO
Standard Colour: Forest Green
Standard Colour: Almond, Black, Burgundy, Electric Blue, Flame Red, Inferno Red, Ivory, Metallic Charcoal, Orange, Patriot Blue, Platinum, White
Standard Seat Colour: Stone Beige
Optional Seat Colours: Black or Oyster
Pinstriping Colours: Pewter, White, Black, Gold
)
)
)
